TRIMETRIC 2030 RV BATTERY SYSTEM MONITOR SERIES
The amps shown on the meter measures whatever current passes through this shunt so it must be wired in series with the wire which carries the current to be measured. A shunt (an accurate, very low resistance power resistor) must be wired into your battery system as described in section B of these instructions, shown on the wiring diagram page 8. For detailed drawings, see application notes on the Bogart Engineering web site under SUPPORT/APPLICATION NOTES: Mounting Drawings for.tm-2020/tm2030. The TM-2030 A can be mounted in many standard double gang electrical boxes available in hardware stores. It can be mounted to a wall with screws at the top and bottom flanges. The TM-2030 RV model comes in a white, surface mount enclosure (3 x 4-1/4 x 1-1/4 inch deep).
TRIMETRIC 2030 RV BATTERY SYSTEM MONITOR SERIAL
See application note on the Bogart Engineering web site under SUPPORT/APPLICATION NOTES entitled : TM-2025-TM-2030 Technical Information on Serial Data Output Mounting the meter: There are two versions of the TM2030 which differ only in their size, front label colors and whether the meter includes its own enclosure. Serial data output is available for all real time data This is a data access method for techies.
It is possible to wire the TriMetric so it reads only total solar input current, or only total load current (and amphours): In this case refer to our web site: BogartEngineering, SUPPORT/APPLICATION NOTES entitled : Using TriMetric for measuring only wind or solar charging source. Lightning considerations: The meter has been designed with good protection against lightning. These levels are described in the TriMetric User s Instructions. L4 adds (only) a more stringent requirement for what is considered to be "charged," intended mainly when using the optional SC-2030 solar charger. For new users, begin with L1, and after becoming familiar with the meter advance to L2 or 元 later at any time. There are also levels L2 or 元 which add more functionality, but with more complexity. You may choose three different operating levels from simplest to more complex: The meter comes initially programmed at the lowest Operating Level: L1 which will furnish the most important data. It should not be connected to systems which will ever exceed 65 volts. Permissible battery voltage: This meter is suitable for battery systems with nominal voltage from 8 to 65 volts. In addition, it will monitor voltage only on a second battery having a common negative connection, which could be the engine starting battery.
TRIMETRIC 2030 RV BATTERY SYSTEM MONITOR FULL
If the optional SC-2030 Solar charger is also to be used, the charger is typically located near the batteries where it can be completely controlled from the TriMetric TM The TM-2030 measures volts, amps, watts, percent full on your main system. For greater distances refer to section B2 for details. It is usually located less than 100 ft from batteries. The TriMetric is usually located in the living area where people using the power can readily observe it. BOGART ENGINEERING Inc Two Bar Road Boulder Creek, CA (831)Ģ A: What you may need to know before installing the TriMetric meter. Contact your dealer or us before shipping.
Any meter not meeting the specification or performance description will be replaced or repaired within four years of purchase, provided it has not been subject to abuse or misapplication, and provided the defective unit is shipped to us if we request it. Meter is warranted for 4 years against any manufacturing defects. Optional: Now or later you may wish to program P4, P5, P6 Limited warranty.
TRIMETRIC 2030 RV BATTERY SYSTEM MONITOR HOW TO
How to program your meter for the 100A/100mV shunt. How to determine program item P3: battery system capacity C2. Program the two most important parameters into meter (section C1).
Follow step by step installation instructions in section B. Consult drawings Figure 1 and 2 (pages 7-8). Please read or scan two pages of introductory information in section A.
TRIMETRIC 2030 RV BATTERY SYSTEM MONITOR INSTALL
If you do not have this knowledge please have someone install it who does, or at least get some competent help to supervise the installation. 1 INSTALLER S INSTRUCTIONS FOR TRI-METRIC Battery system monitor, Models TM-2030-RV and TM-2030-A revised January26, 2016 IMPORTANT: The wiring installation for this meter, especially the shunt installation must be performed by someone knowledgeable in proper wiring, electrical practices, and safety.
